挖沙船的油缸在安装密封圈时该注意的要点
安装密封圈密封能够防止挖沙船的油缸出现漏油的情况，不过在安装密封圈的时候我们要注意一些问题。
1.在安装密封圈之前要检查密封圈的质量是否合格，尤其是唇口的位置，不能够出现有损伤、缺陷。检查完质量之后还要检查密封圈的尺寸是否符合该油缸的尺寸。
2.在安装唇形圈的位置时，例如缸筒和活塞杆的端部，要把它倒成15到30度的倒角，这样能够避免在安装的时候对唇形圈的唇部造成损伤。
3.在安装唇形圈的过程中，如果要经过退刀槽或者螺纹表面的话，最好是在要经过的位置套上专用的套筒。或者在设计的过程中，让螺纹以及退刀槽的直径比唇形圈的内径小。
6.在安装时，尽量减少拉伸度过大，避免塑性发生变形。如果安装的场合气温较低的话，可以把唇形圈放置到60℃左右的热油中加热，但是不能够超出唇形倒的使用温度。
1.在安装密封圈之前要检查密封圈的质量是否合格，尤其是唇口的位置，不能够出现有损伤、缺陷。检查完质量之后还要检查密封圈的尺寸是否符合该油缸的尺寸。
2.在安装唇形圈的位置时，例如缸筒和活塞杆的端部，要把它倒成15到30度的倒角，这样能够避免在安装的时候对唇形圈的唇部造成损伤。
3.在安装唇形圈的过程中，如果要经过退刀槽或者螺纹表面的话，最好是在要经过的位置套上专用的套筒。或者在设计的过程中，让螺纹以及退刀槽的直径比唇形圈的内径小。
4.在安装唇形圈的过程中，如果要经过螺纹表面以及孔口的时候，一定要使用经过位置的内径比唇形圈的外径大的。
6.在安装时，尽量减少拉伸度过大，避免塑性发生变形。如果安装的场合气温较低的话，可以把唇形圈放置到60℃左右的热油中加热，但是不能够超出唇形倒的使用温度。
7.如果工作的压力大于20MPa时，除了要复合唇形圈之外，还要添加挡圈，以免唇形圈被挤出。挡圈最好是装在唇形圈的根部一旁，当随着唇形圈王缸筒里面装入的时候，为了避免挡圈的斜切口被切断，在放入槽沟之后，要使用润滑脂把斜切口粘接固定好再装进去。
以上就是小编今天为大家讲解的挖沙船的油缸在安装密封圈时该注意的要点，你知道了吗？
The installation of seal ring seals can prevent the dredging of the oil tank in the case of oil spills, but in the installation of the seal ring, we should pay attention to some problems.
1. Before installing the sealing ring to check the quality of the seal ring is qualified, especially the position of the lip mouth, can not appear damage, defects. After checking the quality, check the size of the sealing ring to see if it meets the size of the tank.
2. When installing the position of the lip ring, such as the end of the cylinder and the piston rod, it should be poured into a 15-30-degree chamfer, which avoids damage to the lip of the lip ring during installation.
3. In the process of installing the lip ring, if you want to pass the retract groove or threaded surface, it is best to pass the position of the special sleeve. Or in the course of design, let the diameter of the thread and the retract groove be smaller than the inner diameter of the lip ring.
4. In the process of installing the lip-ring, if you want to pass through the surface of the thread and orifice, be sure to use the position of the diameter of the mouth than the size of the lip ring larger.
5. In order to reduce the resistance during assembly, in the process of installation, the lip ring and the place where the grease coated.
6. In the installation, as far as possible to reduce the stretching through large, to avoid plastic deformation. If the temperature of the installation is low, the lip ring can be placed in the heat oil of about 60 Shan, but can not exceed the use of the lip-shaped inverted temperature.
7. If the pressure of the work is greater than 20MPa, in addition to the compound lip-shaped ring, but also to add the ring, lest the lip ring be extruded. The ring is best installed in the lip-ring of the root side, when with the lip-shaped ring in the king cylinder inside the time, in order to avoid the miter ring cut off, after putting into the groove, to use the grease to stick the oblique incision to be fastened and then loaded.
The above is the small compiled today for everyone to explain the dredger oil tank in the installation of the seal ring when the main points, you know?
