想知道绞吸式抽沙船的性能吗?这里有你想要的

      绞吸式抽沙船是一种依靠铰刀对河床进行切割、破碎,然后通过抽沙泵对河沙进行抽取的一种采沙设备。绞吸式抽沙船的用途广泛,可以在江河湖海中进行作业。绞吸式抽沙船除用河沙的抽取之外,还可以用于航道清淤,航道挖掘,吹填造地等等。在特殊情况下绞吸式挖泥船上安装大功率绞刀设备,不需爆破即可挖掘玄武岩和石灰石等岩石地层。

抽沙船
      绞吸式抽沙船的工作效率高,大型的绞吸式挖泥船每小时产量可达几千立方米,大大提高了河沙的产量。绞吸式抽沙船的泵送距离远,它可以把泥沙或碎岩物料依靠强大动力通过泥泵和排泥管线,泵送出几千米之外。
      绞吸式抽沙船的操作简单,易于控制。抽沙船依靠船艉的台车使钢桩定位和前进,利用绞刀桥梁臂两侧横移钢丝绳与连接固定于挖槽两测的锚,靠铰车牵引,通过左右摆动,在一定的控制摆角下工作,将绞刀或斗轮挖掘后的泥沙,经过输泥管泵运送到指定地区。抽沙船的前进由两根桩交替运动,迈步向前。
      大型绞吸式抽沙船带有自航系统.调遣时可以自航到位。中小型抽沙船多为无自航系统,靠拖船拖行。中小型抽沙船可设计建造成组装式,通过陆路运输到现场,经组装后即可使用。绞吸式抽沙船的经济性好。河沙的挖掘和输送可一次性完成,不需其它舶船配合、多次搬运,相对工程成本较低。

挖沙船

  The cutter suction barge is a kind of sand-collecting equipment that relies on reamer to cut and break the riverbed, and then extract the sand by pumping the river. The use of twisted-suction barge is widely used in rivers. In addition to the drainage of the river sand suction barge, can also be used for waterway dredging, waterway excavation, blowing and filling and so on. In special case, the cutter suction dredger installs high-power reamer equipment, and can excavate basalt and limestone rocks without blasting.

  The working efficiency of the cutter suction dredger is high, the large cutter suction dredge can reach thousands of cubic meters per hour, which greatly improves the yield of river sand. The pumping distance of the cutter suction barge is far away, it can rely on the silt or debris material to power through the mud pump and the drainage pipeline, pumping out thousands of meters away.
  The operation of the twisted-suction barge is simple and easy to control. The pumping vessel relies on the stern car of the ship to position and advance the steel pile. Using the Reamer bridge arm lateral shifting wire rope and the connection fixed to the digging groove two measured anchor, relying on the hinge car traction, by swinging around the control pendulum angle, the cutter or bucket wheel after digging the silt, after transporting the mud pipe pump to the designated area. The advance of a pumping vessel is alternating by two piles and moves forward.
  Large-sized twisted-suction barge with a self-navigation system. The fields can be in place. Small and medium-sized sand pumping vessels are not self-navigation system, dragging rows by tugs. Small and medium-sized pumping vessels can be designed and constructed to assemble, transported by land to the site, after assembly can be used. The economical nature of the wring-suction barge. River sand excavation and transportation can be completed one-time, no other ships need to cooperate with many times, relatively low cost.
